Models & Sizes
EUC610TA2
6’ x 10’ Tandem Axle Ultra Classic
- Curb Wt
- 1530 lb
- GVWR
- 7000 lb
EUC612TA2
6’ x 12’ Tandem Axle Ultra Classic
- Curb Wt
- 1635 lb
- GVWR
- 7000 lb
EUC614TA2
6’ x 14’ Tandem Axle Ultra Classic
- Curb Wt
- 1740 lb
- GVWR
- 7000 lb
EUC710TA2
7’ x 10’ Tandem Axle Ultra Classic
- Curb Wt
- 1610 lb
- GVWR
- 7000 lb
EUC712TA2
7’ x 12’ Tandem Axle Ultra Classic
- Curb Wt
- 1715 lb
- GVWR
- 7000 lb
EUC714TA2
7’ x 14’ Tandem Axle Ultra Classic
- Curb Wt
- 1820 lb
- GVWR
- 7000 lb
EUC716TA2
7’ x 16’ Tandem Axle Ultra Classic
- Curb Wt
- 1940 lb
- GVWR
- 7000 lb
EUC718TA2
7’ x 18’ Tandem Axle Ultra Classic
- Curb Wt
- 2060 lb
- GVWR
- 7000 lb
EUC720TA2
7’ x 20’ Tandem Axle Ultra Classic
- Curb Wt
- 2415 lb
- GVWR
- 7000 lb
EUC722TA2
7’ x 22’ Tandem Axle Ultra Classic
- Curb Wt
- 2550 lb
- GVWR
- 7000 lb
Standard Features
- 2 5/16” Coupler with 2K Top Wind Tongue Jack
- 15” Wheels & Tires (Radial)
- Sealed Beam LED Lights
- PPG Primer and Paint
- Tube Tongue (longer than competition)
- Front Fender Step
- Round Tube Top Rail
- Heavy Duty Diamond Plate Fenders
- Ribbed Metal Sides
- 4’ Ramp Gate
- Brakes on Both Axles
- 2” x 6” #2 or Better Fir Decking
Popular Options
- Tongue Box Steel or Aluminum Diamond Plate
- Pressure Treated Decking
- No Gap Stake Pocket Top
- Spare Tire and/or Mount
- Spring Assist for Ramp
- Barn Doors or Swing Tailgate
- Heavy Duty Stored Ramps ILO 4’ Ramp Gate
Specifications
- GAWR
- 7000
- Coupler Height
- 18"
- Deck Height
- 22"
- Frame
- 4" Channel
- Cross Members
- 2" x 3" Angle
- Decking
- 2 x 6 #2 or Better Fir Decking
- Sides
- 24" 16 Gauge Smooth Steel 30" to Top of Rail
- Coupler
- 2 5/16 " Coupler
- Electric Plug
- 7-Way RV Molded Water Tight Plug
- Fenders
- 9" x 66" Smooth
- Finish
- Steel is cleaned (wiped down) to ensure quality protective finish
- Jack
- 2K Top Wind Tongue Jack
- Lights
- Sealed Beam LED Lights
- Paint
- PPG Primer and Paint
- Ramps
- 4' Ramp Tailgate 2" x 2" Frame
- Safety Chain
- 30" x 5/16" 7.6K Capacity
- Suspension
- Multi-Leaf Spring
- Tires
- ST 205/75 R15 Load Range C
- Tongue
- 2" x 4" Rectangular Tube
- Top Rail
- 2" Round
- Uprights
- 2" x 1" Rectangle Tube
- Wheels
- 15 x 5 5-4.5 Mod (Silver)
Available Colors
Primary Colors
Black ALK-FP901
Eagle Majestic Grey
Optional Colors (Additional Cost)
White ALK-FP951
Bright Yellow ALK-FP801
Cat Yellow ALK-FP827
Ford Blue ALK-FP101
Ice Gray ALK-FP301
John Deer Green ALK-FP401
Kubota Orange ALK-FP601
Case IH Red ALK-FP701
